H Series Vacuum Hydrogen Furnace Technical Overview
H Series Vacuum Hydrogen Furnace is a HAOYUE h series vacuum hydrogen furnace solution for hydrogen atmosphere heat treatment. It is designed for demanding research, pilot-scale testing and industrial production where stable temperature, vacuum, pressure, atmosphere control and process repeatability are required.
H Series Vacuum Hydrogen Furnace Applications
- hydrogen atmosphere reduction and heat treatment
- high-purity metal and specialty material processing
- laboratory, pilot and production heat treatment projects
H Series Vacuum Hydrogen Furnace Configuration Options
- Chamber size, usable hot zone, loading method and fixture design
- Working temperature, vacuum level, pressure, atmosphere and cooling method
- Graphite, molybdenum, tungsten or customized hot zone configuration
- PLC control, recipe management, data recording and safety interlock options
Related HAOYUE Furnace Systems
Send material type, part size, target temperature, pressure or atmosphere requirement and production capacity. Contact HAOYUE engineers to request a technical proposal for the h series vacuum hydrogen furnace.
🧩 Product Overview
The H Series Vacuum Hydrogen Furnace is a high-performance vacuum resistance furnace designed for heat treatment, sintering, and purification processes under hydrogen atmosphere.
This system uses:
- Molybdenum strip heating elements
- Hydrogen protective atmosphere
- Vacuum environment
👉 Enabling:
- Oxide reduction
- Metal purification
- High-temperature annealing
Vacuum hydrogen furnaces are widely used for high-temperature processing of metals, ceramics, and composite materials under controlled atmosphere conditions
⚙️ Core Applications
This furnace is widely used in:
- Tool steel, mold steel, high-speed steel
- Stainless steel and non-ferrous metals
- Magnetic materials
- Ceramic and composite materials
👉 Typical applications:
- Hydrogen atmosphere annealing
- Degassing of precious metals
- Brazing and sealing of glass-metal components
- Metal purification and reduction processes
🔬 Working Principle (Vacuum Hydrogen Processing)
The system operates using vacuum + hydrogen atmosphere:
- Workpieces are loaded into the furnace chamber
- Vacuum is established to remove air and contaminants
- Hydrogen gas is introduced as a protective/reducing atmosphere
- Heating system raises temperature
- Oxides are reduced and material purity is improved
👉 Result:
- Clean metal surface
- Reduced oxidation
- Improved material properties
Hydrogen acts as a strong reducing agent, making it ideal for high-purity heat treatment processes
⭐ Key Features & Advantages
✔ Hydrogen Atmosphere Processing (Core Advantage)
- Strong reducing capability
- Prevents oxidation
- Improves material purity
✔ Molybdenum Heating System
- Molybdenum strip heating elements
- Excellent high-temperature mechanical performance
✔ Excellent Temperature Uniformity
- Optimized thermal field design
- Uniform heating distribution
- Stable long-term operation
✔ Fast Heating Performance
- Heating rate:
- 10°C/min (≤1400°C)
✔ High Temperature Control Accuracy
- Precise temperature control system
- Stable process repeatability
✔ Vertical & Horizontal Structure Options
- Vertical (top/bottom loading)
- Horizontal (side loading)
👉 Flexible for different production requirements
✔ Advanced Structural Design
- Double-layer SUS304 stainless steel shell
- Optimized airflow and thermal field
- Modular insulation system
✔ High Safety Performance
- Over-temperature and pressure alarms
- Mechanical pressure protection
- Interlocking safety system
✔ Low Operating Cost
- Energy-efficient design
- Simple installation and maintenance
- Long service life
📊 Technical Specifications (Strictly Based on Product Data)
Typical Models
| Model | Structure | Loading Type | Chamber Size (mm) | Ultimate Vacuum | Max Temperature |
|---|---|---|---|---|---|
| V65/120V | Vertical | Bottom Loading | 650 × 1200 | 6.7×10⁻¹ Pa | 1400°C |
| V65/320V | Vertical | Top Loading | 650 × 3200 | 6.7×10⁻¹ Pa | 1400°C |
| V6MO14 | Horizontal | Side Loading | 600 × 600 × 900 | 6.7×10⁻¹ Pa | 1400°C |
| V7MO14 | Horizontal | Side Loading | 700 × 700 × 1000 | 6.7×10⁻¹ Pa | 1400°C |
| V8MO14 | Horizontal | Side Loading | 800 × 800 × 1200 | 6.7×10⁻¹ Pa | 1400°C |
| V10MO14 | Horizontal | Side Loading | 1000 × 1000 × 1400 | 6.7×10⁻¹ Pa | 1400°C |
📌 All specifications strictly aligned with official product data
🏭 Application Fields
This system is ideal for:
- Heat treatment industry
- Metal processing industry
- Semiconductor and electronic materials
- Advanced materials manufacturing
👉 Especially suitable for:
- Hydrogen annealing
- Metal degassing
- Oxide reduction processes
- High-purity material processing
🚀 Why Choose H Series Vacuum Hydrogen Furnace?
👉 Best for Metal Purification
- Hydrogen atmosphere removes oxides effectively
👉 Best for Heat Treatment
- Ideal for steels, alloys, and magnetic materials
👉 Best for Controlled Atmosphere Processing
- Stable and precise hydrogen environment
⚖️ Position in Product Portfolio
| Series | Function |
|---|---|
| V Series | Vacuum heat treatment |
| P Series | Hot pressing sintering |
| S Series | SPS sintering |
| I Series | Hot isostatic pressing |
| H Series (This Product) | Hydrogen atmosphere heat treatment |
| C Series | CVD / CVI Deposition |
👉 Key difference:
- V Series → Vacuum only
- H Series → Vacuum + Hydrogen (reduction & purification)
🧩 Customization Options
- Vertical or horizontal structure
- Chamber size customization
- Hydrogen control system upgrade
- Automation system integration
🎯 Why Choose Us?
- Professional vacuum hydrogen furnace manufacturer
- Strong expertise in heat treatment and atmosphere control
- Complete furnace product portfolio
- Reliable technical and after-sales support
